Nevalux imani connect B1500 4K
ELDAS® no. 221412
Price: Please log in to see prices
Intelligence
DALI without intelligence
Connect incl. light control
Luminous flux
High Output HO
Medium
Length
1225 mm
1525 mm
- The universal trunking insert imani from nevalux is designed for professional refurbishment of existing trunking with T5 or T8 fluorescent tubes. The luminaire uses the existing trunking installation including existing through-wiring. Old light modules can be replaced with new modules easily, quickly and without tools. The insert fits most trunking systems available on the market. The intelligent imani Connect application variants have permanently installed presence and brightness sensors in conjunction with Bluetooth networking. This results in a powerful light management system as well as unlimited flexibility in the formation of light groups. The savings achieved in addition to the LED technology are considerable and make it possible to claim subsidies.
Identification
Manufacturer
Nevalux
Variants
Intelligence
Connect incl. light control
Luminous flux
Medium
Length
1525 mm
Dimensions
Dimensions L × W × H
1525 x 65 x 30 mm
PU1 net weight
1.9000
Electrical
Mains connection
200...240 V / 50 – 60 Hz
Power
54 W
Replaceable driver
Yes
Type of wiring
Suitable for through wiring
LED rated current
370 mA
Maximum number of luminaires per circuit breaker
C10: 21x, C13: 28x, C16: 36x, C20: 45x, B10: 13x , B13: 17x, B16: 22x, B20: 27x
Sensor technology
Sensor technology
passive infrared
With motion detector
Yes
Detection angle
360°
Radial range
4 x 4 m (16 m²)
Tangential range
6 x 6 m (36 m²)
Mounting height
< 10 m
Presence range
4 x 4 m (16 m²)
Nevalux sensor technology
Smartlink, BT SIG Mesh
With light sensor
Yes
Connectivity
With radio network control
Yes
Lighting technology
Colour temperature
4000 K
LED colour deviation
SDCM3
Colour rendering index
80-89
Illuminant
LED
Luminous flux
6200 lm
Beam angle
105°
Luminaire luminous efficacy
115 lm/W
Glare value
UGR < 24
Lifetime
LED lifespan (25 °C)
50000 h
Settings
DALI dimming
Yes
With emergency light
No
Suitable for light band configuration
Yes
With program-controlled lighting control
Yes
Housing & material
Protection class (IP)
IP40
Protection class
I
Ambient temperature
-20...45 °C
Housing material
Aluminum
Cover material
Diffusor opal
Mounting type
Use in continuous row
Colour
White
Scope of delivery & warranty
Manufacturer warranty
5 years
Certificates & EPREL
EPREL energy efficiency class
E
