Nevalux nefera S V2 Connect CCT
ELDAS® no. 222043
Light colour
Neutral white (4000K)
3000...5700 K
Intelligence
Connect incl. networkable light control
Basic sensor version
- The new nevalux Connect free-standing luminaires impress with their built-in, networkable lighting control system, which is developed in Switzerland. The control system meets all the requirements of a modern lighting management system. Luminaires can be easily combined into groups. The swarm function ensures comfort in open-plan offices and the cleaning light creates the best conditions for cleaning work. The control system is constantly being further developed and fulfils the demands of modern buildings of the future.
Identification
Manufacturer
Nevalux
Variants
Light colour
3000...5700 K
Intelligence
Connect incl. networkable light control
Dimensions
Dimensions L × W × H
726 x 310 x 1954 mm
Electrical
Mains connection
200...240 V / 50 – 60 Hz
Power
80 W
Replaceable driver
Yes
Sensor technology
Sensor technology
passive infrared
With motion detector
Yes
Detection angle
360°
Radial range
4 x 4 m (16 m²)
Tangential range
4 x 4 m (16 m²)
Presence range
4 x 4 m (16 m²)
Nevalux sensor technology
Smartlink, BT SIG Mesh
With light sensor
Yes
Connectivity
With radio network control
Yes
Lighting technology
Colour temperature
3000...5700 K
LED colour deviation
SDCM3
Colour rendering index
80-89
Illuminant
LED
Luminous flux
10400 lm (Down 3850, Up 6550)
Beam angle
Down 80°, Up 115°
Luminaire luminous efficacy
130 lm/W
Glare value
UGR < 18
Lifetime
LED lifespan (25 °C)
50000 h
Settings
DALI dimming
Yes
Direct/indirect ratio separately controllable
No
With program-controlled lighting control
Yes
Constant light output control
Yes
With switch
Yes
Housing & material
Protection class (IP)
IP20
Protection class
I
Ambient temperature
-20...45 °C
Housing material
Aluminum
Cover material
Microprismatic acrylic glass
Mounting type
Free standing floor
Colour
White
Scope of delivery & warranty
Manufacturer warranty
5 years
Certificates & EPREL
EPREL energy efficiency class
D
