Steinel RS PRO 6100 circular SC with motion detector

EAN-No. 4007841089832

ELDAS® no. 089832

Price: Please log in to see prices

Our RS PRO 6100 circular SC luminaire is pioneering in terms of efficiency and sustainability. The low-maintenance, modular luminaire is made from up to 98% recycled plastic. Should components designed for a particularly long service life, such as the sensor, power supply unit or LED board, ever fail, they can be replaced. The basic lighting function and intelligent sensor technology reduce the operating times of the lighting components, further increasing their service life. Whether in industrial environments, car parks and underground garages or in storage and basement areas – the wide beam angles always guarantee maximum light output. And the intelligent sensor technology, in conjunction with Connected Lighting via Bluetooth, always ensures maximum energy efficiency. And to close the circle, thanks to the take-back concept, every luminaire is returned to the material cycle at the end of its long product life. You have our word!

  • Long field luminaire, 1200 mm, with integrated digital high-frequency sensor
  • Ideal for renovating car parks, halls or garages
  • Up to 98% recycled plastic
  • 360° motion detection with ø8 m range, 5-wire through-wired
  • Precise adjustment of range and sensitivity
  • Excellent repairability: power supply unit, sensor and LED card replaceable
  • Robust with IP65 protection class and IK08 impact resistance
  • All settings and networking easily managed via the free Steinel Connect app
  • Suitable for connection to a central battery

Identification

Manufacturer Steinel
E-number 941622309

Dimensions

Dimensions L × W × H 1200 x 90 x 80 mm
PU1 net weight 1.9220

Electrical

Mains connection 220 – 240 V / 50 – 60 Hz
Power 31 W
Own consumption 0,3 W
B10 fuse (pcs) 51.0000
B16 fuse (pcs) 81.0000
C10 fuse (pcs) 74.0000
C16 fuse (pcs) 118.0000

Sensor technology

Max. mounting height 3,50 m
Sensor technology High frequency
Transmission power < 1 mW
HF technology 24 GHz
With motion detector Yes
Detection angle 360 °
Opening angle 160 °
Electronic scalability Yes
Mechanical scalability No
Radial range Ø 8 m (50 m²)
Tangential range Ø 8 m (50 m²)
Mounting height 2 – 3,50 m
Optimal mounting height 2,8 m

Connectivity

Networking Yes
Type of networking Master/master
Networking via Bluetooth Mesh
Slave mode adjustable Yes

Lighting technology

Colour temperature 4000 K
LED colour deviation SDCM3
With illuminant Yes, STEINEL LED system
Illuminant LED can be replaced
Base without
LED cooling system Passive Thermo Control
Soft light start Yes
Continuous light selectable

Lifetime

LED lifetime per IEC 62717 L70 90.000
LED lifetime per IEC 62717 L80 90.000
LED lifetime per IES TM-21 L70 90.000
LED lifetime per IES TM-21 L80 90.000

Settings

Twilight switch Yes
Twilight setting 2 – 2000 lx
Time setting 5 s – 60 Min.
Base light function Yes
Base light function time 5s-60 min Brightness-controlled
Main light adjustable 0 - 100 %
Functions Motions sensor DIM function Dimmkurve individuell einstellbar Adjustable fade time when switching on and off Semi-/fully automatic Light sensor Neighbouring group function Encrypted communication Timer
Settings via App Bluetooth Bluetooth Mesh
With remote control No
Twilight setting teach Yes
Base light function in percent 10 – 100 %
Base light function percent from 10.0000
Base light function percent to 100.0000

Housing & material

Impact resistance IK08
Protection class (IP) IP65
Protection class I
Ambient temperature from -20 up to 40 °C
Housing material Plastic
Cover material PC structured
Mounting location ceiling wall
Application location Indoors
Mounting type Surface wiring
Application room corridor / aisle function room / ancillary room warehouse multi-storey / underground car park production facilities stairwell changing room WC / washroom
Colour grey

Scope of delivery & warranty

Manufacturer warranty 5 years

Certificates & EPREL

EPREL category Surrounded product with integrated light source

Technical drawing

Sensor detection range

Wiring diagram 1

Light with neutral conductor
