Nevalux IR 180 UNIVERSAL weiss
EAN-No. 4007841033149
ELDAS® no. 4007841033149
Price: Please log in to see prices
Manufacturer
Steinel
Nevalux
- Optional adapters made of UV-resistant plastic
- 2 or 3-wire installation
Identification
Version
Presence detector
Manufacturer
Nevalux
E-number
535941667
Variants
Version
2-wire technology
Dimensions
Dimensions L × W × H
50 x 80 x 80 mm
Electrical
Mains connection
220 – 240 V / 50 – 60 Hz
Switching output 1 resistive
200 W
Capacitive load in µF
132 µF
Switching output 1 number of LED/fluorescent lamps
6.0000
Sensor technology
Max. mounting height
1,20 m
Sensor technology
passive infrared
Detection angle
180 °
Opening angle
90 °
Sneak-under protection
Yes
Segment-by-segment masking
No
Electronic scalability
Yes
Mechanical scalability
No
Radial range
r = 4 m (25 m²)
Tangential range
r = 20 m (628 m²)
Switching zones
96 switching zones
Mounting height
1,10 – 1,20 m
Presence range
r = 4 m (25 m²)
Optimal mounting height
1,2 m
Nevalux sensor technology
On / Off
Connectivity
Networking
No
Lighting technology
Soft light start
No
Constant light regulation
No
Settings
Twilight switch
Yes
Twilight setting
2 – 1000 lx
Time setting
30 s – 15 Min.
Base light function
No
Main light adjustable
No
Functions
Switch active / switch inactive\nNormal / test mode\nManual ON / ON-OFF
Settings via
Remote control\nPotentiometers\nSmart Remote
With remote control
No
Twilight setting teach
Yes
Housing & material
Protection class (IP)
IP20
Ambient temperature
0 – 40 °C
Mounting location
wall
Application location
Indoors
Mounting type
Concealed wiring
Material
Plastic
Application room
one-person office\ncorridor / aisle\nfunction room / ancillary room\nkitchenette\nstairwell\nWC / washroom\nIndoors
Colour
white
RAL colour
9010
Scope of delivery & warranty
Manufacturer warranty
5 years
Corner wall bracket included
No
Certificates & EPREL
Certificates
KEMA
