Steinel IR 180 COM1 - white
EAN-No. 4007841029944
ELDAS® no. 029944
Price: Please log in to see prices
Manufacturer
Steinel
Nevalux
New design, intelligent technology, fast installation. IR 180 is the answer to providing infrared sensor switches in new buildings or existing property. 180 denotes the sensor's huge angle of coverage. It misses absolutely nothing, either to the left or right. The IR 180 also comes in a new design and can be installed quickly and easily. The KNX version also indicates temperature and air humidity.
Identification
Version
Presence detector
Manufacturer
Steinel
E-number
535941660
Variants
Version
230V 1 channel
Dimensions
Dimensions L × W × H
30 x 80 x 80 mm
PU1 net weight
0.1190
Electrical
Mains connection
220 – 240 V / 50 – 60 Hz
Power
2000 W
Switching output 1 resistive
2000 W
Fluorescent lamps ECG
1000 W
Fluorescent lamps uncompensated
1000 VA
Fluorescent lamps series-compensated
400 VA
Fluorescent lamps parallel-compensated
500 VA
Switching output 1 low-voltage halogen lamps
2000 VA
LED lamps < 2 W
100 W
LED lamps > 2 W < 8 W
300 W
LED lamps > 8 W
600 W
Capacitive load in µF
176 µF
Switching output 1 number of LED/fluorescent lamps
8.0000
Maximum inrush current
10 A
Sensor technology
Max. mounting height
1,20 m
Sensor technology
passive infrared
With motion detector
Yes
Detection angle
180 °
Opening angle
90 °
Sneak-under protection
Yes
Segment-by-segment masking
No
Electronic scalability
Yes
Mechanical scalability
No
Radial range
r = 4 m (25 m²)
Tangential range
r = 12 m (226 m²)
Switching zones
96 switching zones
Mounting height
1,10 – 1,20 m
Presence range
r = 4 m (25 m²)
Optimal mounting height
1,2 m
Nevalux sensor technology
On / Off
Connectivity
Networking
Yes
Type of networking
Master/master
Master/slave
Networking via
Cable
Lighting technology
Soft light start
No
Continuous light
selectable
Constant light regulation
No
Settings
Twilight switch
Yes
Twilight setting
2 – 1000 lx
Time setting
30 s – 30 Min.
Base light function
No
Main light adjustable
No
Functions
Normal / test mode
Semi-/fully automatic
Switch active / switch inactive
Manual ON / ON-OFF
Settings via
Remote control
DIP switches
Potentiometers
Smart Remote
With remote control
No
Twilight setting teach
Yes
Housing & material
Protection class (IP)
IP20
Ambient temperature
from 0 up to 40 °C
Mounting location
wall
Application location
Indoors
Mounting type
Concealed wiring
Material
Plastic
Application room
one-person office
corridor / aisle
function room / ancillary room
kitchenette
stairwell
WC / washroom
Indoors
Colour
white
RAL colour
9010
Scope of delivery & warranty
Manufacturer warranty
5 years
Corner wall bracket included
No
Media & files
Wiring diagram 3 text
Master/slave interconnection circuit diagram
Cross-/up-selling
Accessories
11257,11259,11255,13686,12367
Optional adapters made of UV-resistant plastic
Technical drawing
Sensor detection range
Wiring diagram 1
Master circuit diagram
Wiring diagram 2
Master/master interconnection circuit diagram
